Product Description
SIM-FMS-004: Au Truck FMS Simulator plus edition, includes all Truck FMS Simulator non-plus edition functions, plus a PC remote terminal for data control and display.
Major Hardware Features:
* SAE J1939-15 Type II ECU, contains an internal 120 ohm load resistor for easy network setup
* Common-Mode Choke and TVS (Transient Voltage Suppressor) protection on CAN bus
* Compact size: 4-1/8" L X 1-3/4"W X 7/8"H
* 9 LED indicators: POWER, RANGE, BTLD, UP+100%, DOWN+0%, 80%, 60%, 40%, 20%, Led will blink when one of these six numeric-specified control point is selected.
* Enclosure color: Black or PC white
* 1 Buzzer
* 3 push buttons: MENU, DOWN, UP, the FMS CAN signal can be adjusted by push buttons
* 1 RS232 interface for software update, license management and remote control (Plus editions only)
* 1 DB9 male connector for Power, Ground, CAN_H and CAN_L
* Accessory cables are available and must be ordered separately, both RS232 Serial Extension Cable (part #: CBL-RS232-01) and 4-wire CAN Cable for DB9 Male Connector (part #: CBL-CAN-01, which provides power supply and CAN network connection to the simulator) are available and must be ordered separately
* Power supply: +9 ~ +12VDC, 250 mA max (+9 V recommended)
* Operating temperature: -4 °F to 185 °F (-20 °C to 85 °C)
Major Operating Features:
* Ease of use - Easy-operate design with production-line-operator and sales person in mind
* Smart features - Recall last operating mode at power-on, capable of generating dynamic data, etc.
* STATIC MODE output steady FMS CAN signal, which can also be adjusted manually
* DYNAMIC MODE automatically generate dynamic FMS CAN signal
* STATIC MODE and DYNAMIC MODE can be easily alternated
* PC remote software is available for all "Plus" editions, it can show simulated FMS signal on a computer screen
* All Control functions are also available from the PC remote software for all "Plus" editions
* Easy In-field license upgrade with Au license management tool.
* For owners with "Truck FMS" Edition(s) or "Bus FMS" Edition(s), when more function is needed, they can be easily upgrade to "Truck and Bus FMS" Edition(s)
* In-field software code (firmware) update Capability for minor upgrades (Order #: SVS-SIM-FMS) with Au PIC Bootloader
* Annual support and minor upgrade services (Order #: SVS-SIM-FMS) are available
* Custom design and modification are available Truck FMS simulator, non-Plus Edition, can statically or dynamically simulate all controller area network (CAN) signal defined by Truck FMS standard.
* Two push buttons (UP and DOWN buttons) are used in the static mode to control the data outputs.
* The dynamic mode will automatically cycling the data in its range (standard defined).
* LEDs will indicate the control status. And Buzzer sound reflects push button inputs.
* The buzzer sound can also be disabled. After a network is physically connected, simply powering up the simulator will get it transmitting CAN data on a truck FMS CAN network.
* No software setup or CAN protocol configuration skill are required.
* Static mode will generate steady Truck FMS CAN data,
* Dynamic mode will generate constant-changing Truck FMS CAN data automatically.
* All Truck FMS standard Ver 01.00 defined CAN parameters are supported by Truck FMS simulator.
Supported Parameters: (designed base on FMS-Standard Vers.02.00):
• Wheel Based Speed
• Clutch switch
• Brake switch
• Cruise control active
• Accelerator pedal position
• Total fuel used
• Fuel level
• Engine speed
• Total Engine Hours
• Vehicle Identification Number
• SW-version supported
• Requests supported
• Diagnostics supported
• High resolution Total vehicle distance
• Drive recognize
• Driver 1 working state
• Driver 1 time related states
• Driver 1 card
• Driver 2 working state
• Driver 2 time related states
• Driver 2 card
• Tachograph vehicle speed
• Direction indicator
• Tachograph performance
• Overspeed
• Handling information
• System event
• Engine coolant Temperature
• Ambient Air Temperature
• Driver 1 identification
• Driver 2 identification
• Fuel Rate
• Instantaneous Fuel Economy
• TP.CM + DT Transport protocol
• Service distance
• Axle location (0, 1, 2) for Axle weight
• Tire location (0, 1, 2, 3) for Axle weight
• Axle weight (00, 01, 10-13, 20-23)
• PTO state
• PTO Driver Engagement
• Engine Percent Load at Current Speed
• High Resolution Fuel Consumption (Liquid): HRLFC
Major Hardware Features:
* SAE J1939-15 Type II ECU, contains an internal 120 ohm load resistor for easy network setup
* Common-Mode Choke and TVS (Transient Voltage Suppressor) protection on CAN bus
* Compact size: 4-1/8" L X 1-3/4"W X 7/8"H
* 9 LED indicators: POWER, RANGE, BTLD, UP+100%, DOWN+0%, 80%, 60%, 40%, 20%, Led will blink when one of these six numeric-specified control point is selected.
* Enclosure color: Black or PC white
* 1 Buzzer
* 3 push buttons: MENU, DOWN, UP, the FMS CAN signal can be adjusted by push buttons
* 1 RS232 interface for software update, license management and remote control (Plus editions only)
* 1 DB9 male connector for Power, Ground, CAN_H and CAN_L
* Accessory cables are available and must be ordered separately, both RS232 Serial Extension Cable (part #: CBL-RS232-01) and 4-wire CAN Cable for DB9 Male Connector (part #: CBL-CAN-01, which provides power supply and CAN network connection to the simulator) are available and must be ordered separately
* Power supply: +9 ~ +12VDC, 250 mA max (+9 V recommended)
* Operating temperature: -4 °F to 185 °F (-20 °C to 85 °C)
Major Operating Features:
* Ease of use - Easy-operate design with production-line-operator and sales person in mind
* Smart features - Recall last operating mode at power-on, capable of generating dynamic data, etc.
* STATIC MODE output steady FMS CAN signal, which can also be adjusted manually
* DYNAMIC MODE automatically generate dynamic FMS CAN signal
* STATIC MODE and DYNAMIC MODE can be easily alternated
* PC remote software is available for all "Plus" editions, it can show simulated FMS signal on a computer screen
* All Control functions are also available from the PC remote software for all "Plus" editions
* Easy In-field license upgrade with Au license management tool.
* For owners with "Truck FMS" Edition(s) or "Bus FMS" Edition(s), when more function is needed, they can be easily upgrade to "Truck and Bus FMS" Edition(s)
* In-field software code (firmware) update Capability for minor upgrades (Order #: SVS-SIM-FMS) with Au PIC Bootloader
* Annual support and minor upgrade services (Order #: SVS-SIM-FMS) are available
* Custom design and modification are available Truck FMS simulator, non-Plus Edition, can statically or dynamically simulate all controller area network (CAN) signal defined by Truck FMS standard.
* Two push buttons (UP and DOWN buttons) are used in the static mode to control the data outputs.
* The dynamic mode will automatically cycling the data in its range (standard defined).
* LEDs will indicate the control status. And Buzzer sound reflects push button inputs.
* The buzzer sound can also be disabled. After a network is physically connected, simply powering up the simulator will get it transmitting CAN data on a truck FMS CAN network.
* No software setup or CAN protocol configuration skill are required.
* Static mode will generate steady Truck FMS CAN data,
* Dynamic mode will generate constant-changing Truck FMS CAN data automatically.
* All Truck FMS standard Ver 01.00 defined CAN parameters are supported by Truck FMS simulator.
Supported Parameters: (designed base on FMS-Standard Vers.02.00):
• Wheel Based Speed
• Clutch switch
• Brake switch
• Cruise control active
• Accelerator pedal position
• Total fuel used
• Fuel level
• Engine speed
• Total Engine Hours
• Vehicle Identification Number
• SW-version supported
• Requests supported
• Diagnostics supported
• High resolution Total vehicle distance
• Drive recognize
• Driver 1 working state
• Driver 1 time related states
• Driver 1 card
• Driver 2 working state
• Driver 2 time related states
• Driver 2 card
• Tachograph vehicle speed
• Direction indicator
• Tachograph performance
• Overspeed
• Handling information
• System event
• Engine coolant Temperature
• Ambient Air Temperature
• Driver 1 identification
• Driver 2 identification
• Fuel Rate
• Instantaneous Fuel Economy
• TP.CM + DT Transport protocol
• Service distance
• Axle location (0, 1, 2) for Axle weight
• Tire location (0, 1, 2, 3) for Axle weight
• Axle weight (00, 01, 10-13, 20-23)
• PTO state
• PTO Driver Engagement
• Engine Percent Load at Current Speed
• High Resolution Fuel Consumption (Liquid): HRLFC
Additional Information
| Version | 1.00A |
| Edition | Truck FMS Plus Edition |
| Au Part # | SIM-FMS-004 |
